MFD-10KVA
Microprocessor control 10KVA automatic voltage regulator with bypass function
ITEM NO: MFD-10KVA
· Power: 10000VA
·Technology: CPU based digital Circuit + Transformer
·Input Voltage: 120-260 VAC /80-140 VAC
·Input Frequency: 50/60Hz
·Output Voltage: 220 VAC / 110 VAC
·Output Precision: +/-10%
·DelayTime: 6 secs / 180 secs
·Efficiency: 98%
·Phase: Single phase
·LED Digital Display Status: Input voltage / Output voltage
·AVR & Bypass Function
·High Voltage Protection:Yes
·Low Voltage Protection: Yes
·Overload Protection: Yes
·High Temperature Protection: Yes
·Circuit protection: circuit breaker
·Smart Cooling System: Yes
·Safety Standards: CE, EN 60335, EN 61000
·Operating Temperature: 0~40℃
·Storage Temperature: -15℃~45℃
·Operating Relative Humidity: 10%RH~102%RH
·Machine Size(mm): 445 x 215 x 260mm
·N.W.(Kgs): 23Kg
