ITEM NO: PV2412-6

• Input voltage: 20V DC to 30V DC
• Output voltage: 12V DC to 13.8V DC
• Standby current: ≤15mA
• Output power: 6A (continuous), 7.5A (maximum)
• Input fuse: 7.5A, Standard auto blade fuse (Internal*)
• Connection cable: 1.5mm2 / 900mm.
• Efficiency: 85% to 90%
• Thermal shutdown: 65℃+/-5℃
• Input polarity reverse diode protection
• Output polarity reverse circuit protection
• Output short-circuit protection
• Overheating circuit protection
• Overload circuit protection
• Operating temperature: 0~40℃
• Storage temperature:: -15℃~45℃
• Operating relative humidity: 10%RH~102%RH,
• Compliant standards: CE, e8 ,EN61000, 2006/96/EC.
• Dimension: 88 x 87 x 42mm
• Net weight: 0.35kg
