ITEM NO:  PV2412-60

• Input voltage: 20V DC to 30V DC
• Output voltage: 12V DC to 13.8V DC
• Standby current: ≤90mA
• Output power: 60A (continuous), 80A (maximum)
• Input fuse: 2×30A, Standard auto blade fuse (Internal)
• Connection cable: 12mm2/900mm
• Efficiency: 85% to 90%
• Thermal shutdown: 65℃+/-5℃
• Cooling fan: Yes auto-operation fan (temperature or load)
• Input polarity reverse diode protection
• Output polarity reverse circuit protection
• Output short-circuit protection
• Overheating circuit protection
• Overload circuit protection.
• Operating temperature: 0~40℃
• Storage temperature:: -15℃~45℃
• Operating relative humidity: 10%RH~102%RH,
• Compliant standards: CE, EN61000, 2006/28/EC.
• Dimension: 275×165×79mm mm
• Net weight: 2.0kg
